Pressure transducer
power: Kw
Production: m3/min
Exhaust:MPa
Drive mode:
Cooling method:
Working principle
The pressure sensor diffuses a Wheatstone bridge on a silicon wafer and the bridge dielectric resistance (piezoresistive) changes by applying pressure to the medium under test (gas or liquid) to create a differential voltage signal. This signal through a dedicated amplifier, the corresponding range of the signal into a standard analog signal or digital signal.
Features
Adopt imported silicon pressure sensitive original and advanced diaphragm isolation technology
Compact structure, easy installation
Wiring reverse and overvoltage protection, current limiting protection
High precision, stable, fast response, impact resistance
Applicable site
Suitable for indoor, installation space limited liquid or gas pressure measurement.
