Requirements for installation of air tank for air compressor:
1, storage capacity, on the one hand to solve the system within a short time may be greater than supply demand contradiction, on the other hand, failure or other unexpected events in the air compressor (such as power outages) for temporary emergency;
2, eliminate or weaken the pulsation of the air flow of the piston type air compressor, stabilize the pressure of the gas source, and ensure the continuous and smooth flow of the output air.
3, provide a larger system capacity, extend the cycle of air compressor start stop or loading unloading cycle, and reduce the switching frequency of electrical equipment and valves.
4, further cooling air separation and removal of impurities in the air, compressed water pollution, reduce the work load of network downstream other postprocessing equipment, make all kinds of gas equipment to obtain the required quality of the gas storage tank; small air compressor is used to install a pedestal with the compressor body and other accessories.
5, gas supply system, gas storage tank is generally installed in the rear cooler, it can prevent the aggregation of oil vapor and liquid water in the tank, in order to reduce security risks and improve the source of other equipment work as much as possible; in addition, stored in a tank of air at low temperature can also reduce the volume of the body.
In most situations, the gas tank are installed in the front of the dryer, so that the gas storage tank with cooling water and the role of regulator, the dryer load can be reduced, and the air pressure into the dryer is relatively stable, it is very beneficial to the operation of the dryer.
6, but the gas tank installed in front of the dryer also has the following disadvantages: if there is a lot of condensate in the tank, liquid water will enter the dryer with air flow and increase its operation load.
7, in addition, if the inner wall of gas storage tank is in a humid environment for a long time, it will rust easily, which will not only affect the service life of the body, but also cause many adverse effects on the rust and spalling. In order to avoid the occurrence of the above conditions, it is very important to discharge the gas tank in time.
When used with continuous gas supply equipment such as screw compressor, the gasholder can be installed behind the dryer. When the air entering the storage tank is dry, there is no condensate in the tank, which avoids the above defects. But this arrangement also has disadvantages: first, the inlet temperature of dryer is close to the rear cooler outlet temperature, the ratio of buffer tank is much higher, and the rear cooler outlet flow carried by the liquid water may directly into the dryer, the running load increases. In addition, a large pressure drop will be produced after the air flow through the dryer, filter and other purification equipment, so that the air pressure to the gas tank is reduced.
To sum up, the specific installation position of the gas storage tank should be determined by a variety of factors when the system is designed.
